In the world of high-performance automotive builds, the fuel system is the heartbeat of your engine. Whether you are building a dedicated drift car, a drag racer, or restoring a classic, the stock mechanical pump often falls short.
This is where electric fuel pumps come into play. Specifically, for those using aftermarket fuel cells or chasing high horsepower numbers, the inline fuel pump is often the industry standard solution. This guide breaks down how they work, why you might need one, and how to install them correctly.
In modern automotive engineering, electric fuel pumps have replaced mechanical ones to provide consistent, high-pressure fuel delivery independent of engine RPM. They are the standard for all fuel-injected vehicles.
They generally fall into two categories:
In-Tank Pumps: Submerged inside the fuel tank.
Inline Pumps: Mounted outside the tank, typically on the chassis frame rail.
Definition: An inline fuel pump is an external electric pump installed in the fuel line between the tank and the engine.
While in-tank pumps are quiet and great for daily drivers, an inline fuel pump is often preferred for modified vehicles, especially when paired with a racing fuel cell.
Universal Fitment: Most aftermarket fuel cells do not have provisions for an OEM drop-in pump. An inline pump is the universal solution for these setups.
Ease of Maintenance: If a pump fails at the track, an inline pump can be swapped in minutes without dropping the tank or draining fuel.
High Power Support: Inline pumps can easily be run in parallel (dual pump setups) to support massive horsepower figures (1000hp+) that a single in-tank pump cannot handle.
To help you decide, here is a breakdown of how these electric fuel pumps differ in application:
When shopping for fuel pumps and accessories, you will see numbers like "255," "340," or "044." These refer to the flow rate.
Flow Rate (LPH): Liters Per Hour. A 255 LPH pump is a common upgrade for street builds (up to ~500hp), while 300+ LPH pumps are needed for high-boost applications.
Pressure (PSI): Ensure the pump can maintain its flow rate at your required fuel pressure. Turbocharged cars raise fuel pressure as boost rises, so the pump must be strong enough to push against that resistance.
The number one reason for inline fuel pump failure is incorrect installation. These pumps are designed to push fuel, not pull it. To ensure longevity and reliability, follow these rules:
Because inline pumps are poor at suction, they must be mounted below the lowest point of the fuel tank or fuel cell. This allows gravity to flood the pump inlet, preventing "cavitation"—air pockets that cause the pump to overheat and fail.
You cannot run an electric pump without filters.
Pre-Filter (100 Micron): Install a coarse filter between the tank and the pump. This catches large debris that could jam the pump mechanism.
Post-Filter (10-40 Micron): Install a fine filter after the pump but before the engine. This protects your fuel injectors.
High-performance electric fuel pumps draw significant current. Never wire them directly to a thin stock wire. Always use a dedicated relay and heavy-gauge wire connected directly to the battery to ensure the pump receives full voltage. A drop in voltage equals a drop in fuel flow, which can destroy an engine.
The fuel system is not the place to cut corners. Whether you are converting a carburetor to EFI or installing a fuel cell for track days, an inline fuel pump offers the reliability and performance flexibility that serious builds require.
By choosing the correct flow rate and following the "gravity feed" installation rule, your fuel system will support your horsepower goals safely.
Ready to fuel your passion? 👉 Explore our range of High-Performance Electric Fuel Pumps here.
Q: Are inline fuel pumps loud?
A: Yes, compared to in-tank pumps. Because they are mounted externally to the chassis, you will hear a distinct hum or buzz when the car is running. Using rubber isolator mounts during installation can significantly reduce this vibration noise.
Q: Can I use an inline fuel pump with a stock gas tank?
A: Yes, but it usually requires modifying the fuel pickup line or installing a "sump" on the bottom of the stock tank to ensure the pump is gravity-fed. For stock tanks, a high-flow in-tank pump is usually easier to install.
Q: How do I know if my electric fuel pump is bad?
A: Common signs include a whining noise that is louder than usual, difficulty starting the car (requiring multiple key turns to prime), or sputtering/power loss at high RPMs due to fuel starvation.
